Technical Parameters : Detection Range: 180° / 360° Power Source: 220V / 240V AC Power Frequency 50/60Hz Rated Load: Max 1200W (Incandescent) 300W (Florescent) Detection Distance 12M Max (<24°c) Time Delay: Min. 10Sec ± 3sec , Max 15min ± 2min Ambient Light: <3-2000LUX (adjustable) Working Temperature: -20~ 40°c Working Humidity: <90%RH Power Consumption: approx. 0.5W Installation Height: 1.8M – 2.5M Detection Moving Speed: 0.5 – 1.5m/s INSTALLATION ADVICE : As the detector respond to changes in temperature, avoid the following situations: Avoid pointing the detector towards object with high reflective surfaces, such as mirrors, etc. Avoid mounting the detector near heat sources, such as heating vents, air-conditioning Units, lights etc. Avoid pointing the detector towards object that may move in the wind such as curtains, tall plants etc. WARNING: Danger of death through electric shock! • Must be installed by professional electrician • Disconnect power source • Cover or shied any adjacent live components • Ensure device cannot be switched on • Check the power supply is disconnected
